2006 Progress Report: Phytoremediation of Heavy Metal Contamination by Metallohistins, a New Class of Plant Metal-Binding Proteins
EPA Grant Number: R829479C021Subproject: this is subproject number 021 , established and managed by the Center Director under grant R829479
(EPA does not fund or establish subprojects; EPA awards and manages the overall grant for this center).
Center: The Consortium for Plant Biotechnology Research, Inc., Environmental Research and Technology Transfer Program
Center Director: Schumacher, Dorin
Title: Phytoremediation of Heavy Metal Contamination by Metallohistins, a New Class of Plant Metal-Binding Proteins
Investigators: Cheng, Zong-Ming
Institution: University of Tennessee
EPA Project Officer: Aja, Hayley
Project Period: October 1, 2004 through September 30, 2007 (Extended to December 31, 2007)
Project Period Covered by this Report: October 1, 2005 through September 30, 2006
RFA: The Consortium for Plant Biotechnology Research, Inc., Environmental Research and Technology Transfer Program (2001) RFA Text | Recipients Lists
Research Category: Hazardous Waste/Remediation , Targeted Research
Objective:
The objectives are:
- To construct the transformation vectors with the already cloned metallohistin cDNA agNt84 under control by constitutive promoter CaMV35S.
- To transfer the genes into a woody plant, a Populus hybrid, and annual plants, Brassica napus and B. juncea, and to confirm transformation by polymerase chain reaction and Southern blot.
- To determine levels of RNA and protein expression in different tissues.
- To characterize the transgenic plants for their metal accumulation capacity and phytoremediation potential.
- To determine the short- and long -term effects of the overexpression of metallohistin on growth and development of the transgenic plants.
Progress Summary:
Cloning of AgNt84 in a Binary Vector Under the Control of CaMV35S Promoter
AgNt84 was PCR amplified from the initial cDNA clone using forward 5’CAGCGGATCCCATTGTCTCCAATCCTCTTCA3’ and reverse primer 5’TGACGAGCTCAGACGTACGTACAACTGATAGCAT3’, which introduced BamHI and SacI sites, respectively. The BamHI-SacI fragment was then ligated into pBI121, in front of a CaMV35S promoter as shown in Figure 1.
Figure 1. pBINAgNt84: Binary Vector Used for Transformation
Plant Transformation
The vector was introduced into Agrobacterium tumefaciens strain GV3850, and Populus and Brassica plant transformation was initiated. Because Populus and Brassica transformation is slower, we proceeded to transform tobacco and Arabidopsis in order to evaluate the construct. Arabidopsis thaliana ecotype Col1 plants were transformed by the floral dip method and Nicotiana tabacum cv. Xanthi were transformed by the leaf disc transformation method.
The gene was later transformed into Populus tree. We have obtained 80 kanamycin-resistant hybrid aspen plants (Figure 2). Leaves collected from about 2-month- old transgenic plants, grown in the culture room, were confirmed by PCR (Figure 3). Currently, 18 putatively transformed plants have been confirmed by PCR. An additional 60 -80 plants will be confirmed by PCR. Southern blots will be performed to determine the copy numbers. For the confirmed aspen lines, each line has approximately 2 -6 copies. We will multiply each line to about 10 plants for heavy metal test for phytoremediation.
Figure 2. Kanamycin-Resistant Poplar Plants Figure 3. PCR Confirmation
Transgenic Brassica jancea has also been obtained. Confirmation has also been done with PCR.
Transgenic Plants Express AgNt84 and Appear Normal
Expression of AgNt84 was confirmed by northern blot (Figure 4). The protein, however, was in an unextractable form, tightly bound to the cell wall. Immunostaining of cell wall pellets showed a strong fluorescent signal from transgenic plants compared to controls (Figure 5). Overall, transgenic plants appeared normal, indicating that overexpression of a metallohistin gene did not interfere with normal plant cell metabolism.
Figure 4. Northern Blot of Transgenic Arabidopsis Lines. Ten μ g total RNA was run and probed with the AgNt84 cDNA clone. Bottom panel is 18S RNA shown for equal loading.
Figure 5. Immunostaining of Pellets From Cell Wall Protein Extraction Show That AgNt84 is Still Tightly Bound Within the Cell Wall. Immunostaining was performed with rabbit preimmune and anti-AgNt84 immune serum, followed by incubation with FITC-linked Goat Anti-rabbit IgG as the secondary antibody.
Transgenic Plants Accumulate More Cadmium
Preliminary experiments were conducted to assess the metal binding ability of transgenic plants by a dithiazone staining method. Tobacco plants hydroponically grown in 5 mM MES buffer without Cd showed no staining characteristic of Cd accumulation. When grown on buffer containing 200 mM Cd(NO3)2, staining was observed starting from day 1 in root tissue (Figure 6).
Figure 6. Metal Binding in Transgenic Tobacco: Dithizone Staining of Tobacco Wild-Type (WT) and Transgenic Lines T12 and T17 Hydroponically Grown in the
Presence or Absence of 200 mM Cd (NO3)2. Arrows indicate staining resulting from the formation of Cd dithizonate. The color of dithizonate ranges from
an orange red to red-violet color in order of increasing Cd concentration in the tissue. Intense staining is observed with transgenic plants compared to WT.
Future Activities:
The project is progressing according to schedule. Additional B. jancea will be produced and confirmed. Transgenic poplar plants will be confirmed with Southern blots to determine the copy number and will be determined for actual gene expression by northern blot. Year 2 will focus on the metal binding in both poplar and B. jancea to determine the plant growth under heavy metal stress
Journal Articles:
No journal articles submitted with this report: View all 1 publications for this subprojectSupplemental Keywords:
genetic engineering, heavy metal contamination, phytoremediation,, Scientific Discipline, Waste, TREATMENT/CONTROL, POLLUTANTS/TOXICS, Treatment Technologies, Technology, Chemicals, Biochemistry, Bioremediation, Molecular Biology/Genetics, Biology, plant-based remediation, metallohistins, transgenic plants, plant uptake studies, biotechnology, plant biotechnology, phytoremediationProgress and Final Reports:
