2005 Progress Report: Phytoremediation of Heavy Metal Contamination by Metallohistins, a New Class of Plant Metal-Binding Proteins

EPA Grant Number: R829479C021
Subproject: this is subproject number 021 , established and managed by the Center Director under grant R829479
(EPA does not fund or establish subprojects; EPA awards and manages the overall grant for this center).
Center: The Consortium for Plant Biotechnology Research, Inc., Environmental Research and Technology Transfer Program
Center Director: Schumacher, Dorin
Title: Phytoremediation of Heavy Metal Contamination by Metallohistins, a New Class of Plant Metal-Binding Proteins
Investigators: Cheng, Zong-Ming
Institution: University of Tennessee
EPA Project Officer: Aja, Hayley
Project Period: October 1, 2004 through September 30, 2007 (Extended to December 31, 2007)
Project Period Covered by this Report: October 1, 2004 through September 30, 2005
RFA: The Consortium for Plant Biotechnology Research, Inc., Environmental Research and Technology Transfer Program (2001) RFA Text |  Recipients Lists
Research Category: Hazardous Waste/Remediation , Targeted Research

Objective:

The objectives of this research project are to: (1) construct the transformation vectors with the already cloned metallohistin cDNA agNt84 under control by constitutive promoter CaMV35S; (2) transfer the genes into a woody plant, a Populus hybrid, and annual plants, Brassica napus and B. juncea, and confirm transformation by polymerase chain reaction (PCR) and Southern blot; (3) determine levels of RNA and protein expression in different tissues; (4) characterize the transgenic plants for their metal accumulation capacity and phytoremediation potential; and (5) determine the short- and long-term effects of the overexpression of metallohistin on growth and development of the transgenic plants.

Progress Summary:

Objective 1: To Construct the Transformation Vectors With the Already Cloned Metallohistin cDNA agNt84 Under Control By Constitutive Promoter CaMV35S

AgNt84 was PCR amplified from the initial cDNA clone using forward 5’CAGCGGATCCCATTGTCTCCAATCCTCTTCA3’ and reverse primer 5’TGACGAGCTCAGACGTACGTACAACTGATAGCAT3’, which introduced BamHI and SacI sites, respectively. The BamHI-SacI fragment was then ligated into pBI121, in front of a CaMV35S promoter as shown in Figure 1. The vector was introduced into Agrobacterium tumefaciens strain GV3850.

Figure 1. pBINAgNt84: Binary Vector Used for Transformation

Objective 2: To Transfer the Genes Into a Woody Plant, a Populus Hybrid, and Annual Plants, Brassica juncea, and To Confirm Transformation by Polymerase Chain Reaction and Southern Blot

Because Populus and Brassica transformation is slower, we proceeded to transform tobacco and Arabidopsis to evaluate the construct. Arabidopsis thaliana ecotype Col1 plants were transformed by the floral dip method [1] and Nicotiana tabacum cv Xanthi were transformed by the leaf disc transformation method.

Objective 3: To Determine Levels of RNA and Protein Expression in Different Tissues

Expression of AgNt84 was confirmed by northern blot (Figure 2). The protein, however, was in an unextractable form, tightly bound to the cell wall. Immunostaining of cell wall pellets showed a strong fluorescent signal from transgenic plants compared to controls (Figure 3).

Figure 2. Northern Blot of Transgenic Arabidopsis Lines. Ten μg total RNA was run and probed with the AgNt84 cDNA clone. Bottom panel is 18S RNA shown for equal loading.

Figure 3. Immunostaining of Pellets From Cell Wall Protein Extraction Show That AgNt84 is Still Tightly Bound Within the Cell Wall. Immunostaining was with rabbit preimmune and anti-AgNt84 immune serum, followed by incubation with FITC-linked goat anti-rabbit IgG as the secondary antibody.

Objective 4: To Characterize the Transgenic Plants for Their Metal Accumulation Capacity and Phytoremediation Potential

Preliminary experiments were conducted to assess the metal binding ability of transgenic plants by a dithiazone staining method. Tobacco plants hydroponically grown in 5 mM MES buffer without Cd showed no staining characteristic of Cd accumulation. When grown on buffer containing 200 mM Cd(NO₃)₂, staining was observed starting from day 1 in root tissue (Figures 4 and 5 and Table 1).

rubber band disk

tube buffer band

Figure 4. Hydroponically Grown Tobacco Plants. The first two figures are diagrams of the setup of the hydroponic containers, and the remaining pictures are of the plants at various steps in the metal uptake experiment. A. A diagram of the disk in the container. The view is through the opening of the petri dish container. The disk can easily be moved in and out of the container, which facilitates rinsing the plants. Each plant is placed in a hole in the disk. B. A diagram of the setup of the hydroponic container. The disk is above the buffer or media so that the roots are in contact. In addition, the microfuge tubes hold up the disk to allow the disk to remain above the buffer or media. C. Picture of tobacco plants hydroponically grown in MS. D. Tobacco plants in the process of being rinsed with water in the laminar flow hood. E. Tobacco plants in MES buffer containing 200 μM Cd(NO₃)2 4H₂O. A bigger lid was used to accommodate the size of the plants. The picture was taken after the plants were rinsed with water.

Figure 5. Metal Binding in Transgenic Tobacco: Dithizone Staining of Tobacco WT and Transgenic Lines T12 and T17 Hydroponically Grown in the Presence or Absence of 200 mM Cd (NO₃)₂. Arrows indicate staining resulting from the formation of Cd dithizonate. The color of dithizonate ranges from an orange-red to red-violet color in order of increasing Cd concentration in the tissue. Intense staining is observed with transgenic plants compared to WT.

Table 1. Cadmium Uptake of T10, T12, T17, and Wild-Type Tobacco on 200 mm Cd. Blank areas indicate where sample was lost during processing, and NC indicates where no calculation was done because the amount of cadmium was below detection levels. A. Blank samples. B. Day1 samples. C. Day 3 samples.

A. Blanks – No Incubation With Cadmium.

Shoot				Root				Total dry mass (g)
Tobacco Line	g	mg/L Cd	mg Cd/g dry wt.	Tobacco Line	g	mg/L Cd	mg Cd/g dry wt.
WT	0.41	0.017	4.09	WT	0.07	0.0015	2.14	0.48
WT	0.43	<0.001	NC	WT	0.07	<0.001	NC	0.50
WT	0.32	0.001	0.31	WT	0.07	<0.001	NC	0.39
10	0.26	<0.001	NC	10	0.05	<0.001	NC	0.31
10	0.06	<0.001	NC	10	0.06	<0.001	NC	0.06
10	024	0.014	5.71	10	0.05	0.0046	9.2	0.29
12	0.13	<0.001	NC	12	0.04	<0.001	NC	0.17
12	0.30	<0.001	NC	12	0.05	<0.001	NC	0.35
12	0.22	<0.001	NC	12	0.04	0.0046	11.5	0.26
17	0.30	<0.001	NC	17	0.07	<0.001	NC	0.37
17	0.23	<0.001	NC	17	0.03	<0.001	NC	0.26

B. Day 1 – Incubation With Cadmium for 1 Day.

Shoot				Root				Total dry mass (g)
Tobacco Line	g	mg/L Cd	mg Cd/g dry wt.	Tobacco Line	g	mg/L Cd	mg Cd/g dry wt.
WT	0.30	4.879	1,626	WT	0.06	4.880	8,133	0.36
WT	0.19	0.988	520	WT	0.05	3.669	7,338	0.24
WT	0.23	0.333	145	WT	0.08	3.334	4,168	0.31
WT	0.16	0.311	194	WT	0.04	2.181	5,453	0.20
WT	0.21	1.226	584	WT	0.05	6.070	12,140	0.26
10	0.33	1.686	511	10	0.07	6.000	8,571	0.40
10	0.16			10	0.03	5.860	19,533	0.19
10	0.22	2.576	1,171	10	0.05	8.280	16,560	0.27
12	0.16	1.309	818	12	0.04	4.786	11,965	0.20
12	0.16	1.275	797	12	0.02	4.126	20,630	0.18
12	0.22	3.170	1,441	12	0.05	7.290	14,580	0.27
17	0.22	1.850	841	17	0.07	7.540	10,771	0.29
17	0.29	3.421	1,180	17	0.07	6.460	9,229	0.36

C. Day 3 – Incubation With Cadmium for 3 Days.

Shoot				Root				Total dry mass (g)
Tobacco Line	g	mg/L Cd	mg Cd/g dry wt.	Tobacco Line	g	mg/L Cd	mg Cd/g dry wt.
WT	0.07	1.973	2,819	WT	0.10	5.490	5,490	0.17
WT	0.41	2.505	611	WT	0.13	7.110	5,469	0.54
WT	0.24			WT	0.11	5.370	4,881	0.35
WT	0.23			WT	0.04	3.280	8,200	0.27
WT	0.34	1.094	322	WT	0.15	6.910	4,607	0.49
WT	0.31	2.834	914	WT	0.08	9.360	11,700	0.39
WT	0.18	1.618	899	WT	0.05	5.980	11,960	0.23
10	0.77	7.460	969	10	0.16	14.360	8,975	0.93
10	0.18	3.384	1,880	10	0.04	8.140	20,350	0.22
10	0.35	5.610	1,603	10	0.08	12.110	15,138	0.43
12	0.21			12	0.07	10.230	14,614	0.28
12	0.17	0.976	574	12	0.02	4.792	23,960	0.19
12	0.29	4.202	1,450	12	0.11	11.400	10,364	0.40
12	0.28	2.005	716	12	0.07	7.760	11,086	0.35
12	0.22	10.440	4,745	12	0.06	7.430	12,383	0.28
17	0.20	2.646	1,323	17	0.06	6.580	10,967	0.26
17	0.21	3.691	1,758	17	0.26	7.970	3,065	0.47
17	0.43	2.635	618	17	0.13	16.080	12,369	0.56

Objective 5: To Determine the Short- and Long-Term Effects of the Overexpression of Metallohistin on Growth and Development of the Transgenic Plants

Overall, transgenic plants appeared normal, indicating that overexpression of a metallohistin gene did not interfere with normal plant cell metabolism.

Future Activities:

After we demonstrated the feasibility in plants (tobacco and Arabidopsis), we are in the process of transforming Populus and Brassica juncea. After transformation is confirmed, we will characterize metal binding and accumulations.
