Final Report: Characterizing the Intrinsic Remediation of MTBE at Field Sites
EPA Grant Number: R828598C791Subproject: this is subproject number 791 , established and managed by the Center Director under grant R828598
(EPA does not fund or establish subprojects; EPA awards and manages the overall grant for this center).
Center: Texas - Indiana Virtual STAR Center
Center Director: Gustafsson , Jan-Ake
Title: Characterizing the Intrinsic Remediation of MTBE at Field Sites
Investigators: Rifai, Hanadi , Rixey, William G.
Institution: University of Houston - University Park
EPA Project Officer: Aja, Hayley
Project Period: September 1, 2000 through August 31, 2004
RFA: Gulf Coast Hazardous Substance Research Center (Lamar University) (1996) RFA Text | Recipients Lists
Research Category: Hazardous Waste/Remediation , Targeted Research
Objective:
MTBE, a common oxygenate, is used in 30% of the nation’s gasoline and usually composes 11 to 15% of the gasoline product. Although MTBE has beneficial properties for improving air quality, it also has several characteristics that make it a highly mobile groundwater contaminant. Recent studies in the literature documented the presence of MTBE in many of the nation’s groundwater aquifers. Initially thought recalcitrant, more current research points to the biodegradability of MTBE under aerobic and anaerobic conditions. In light of MTBE’s economic impact (in Texas alone, the MTBE industry accounts for approximately 25,000 jobs), and the lack of consensus on replacement additives, studies are needed to fully characterize MTBE’s behavior at the field scale and develop a better understanding of its attenuation potential on an individual site basis and on a more global scale as a gasoline additive.
This study develops a database of 127 MTBE sites and uses the historical data gathered at the selected sites to evaluate the MTBE plume spatially and temporally. Historical concentration data in individual wells were studied to determine trends over time. In order to assess overall plume status, the concentrations in source and tail wells at each site were analyzed using the Mann Kendall (MK) and linear regression statistical trend analysis methods. Overall plume stability was further evaluated by estimating the dimensions of the plume over time.
Attenuation rates were calculated for each site using concentration-time plots (point attenuation) and concentration distance plots (bulk attenuation). The bulk-attenuation analysis could only be completed for six sites out of the 127 in the database due to the lack of wells along the centerline. Geochemical indicator data were reported for only 22 of the 127 sites in the database, and were not used in the analysis due to the poor data quality.
Summary/Accomplishments (Outputs/Outcomes):
The project resulted in four peer reviewed publications and numerous presentations and conference proceedings papers. Two students received their master’s degrees as a result of the project funding and are currently employed in the private sector. The project also helped a post-doctoral researcher re-enter the workforce after a parenting leave.
A database of 127 sites was assembled for leaking petroleum storage tank (LPST) sites contaminated with MTBE using the Texas Commission of Environmental Quality (TCEQ) site records. A large percentage (61%) of the sites in the database were located along the Gulf Coast. The remaining sites cover most areas across Texas and therefore represent several geologies and lithologies. The 127 sites had mostly shallow groundwater (less than 30-ft (9.1-m) below ground surface) and the impacted water zone was not a drinking water source. The monitoring well networks at the 127 sites consisted of 12 monitoring wells on average but ranged from a minimum of 6 to a maximum of 64 wells.
The data in Figure 1 show the distribution of tank installation dates for the 127 sites. As can be seen, most sites began operation between 1969 and 1986 with more than half the PSTs installed prior to 1979 indicating the possibility of leaks that pre-date MTBE addition to gasoline. The data in Figure 2 indicate most PSTs were removed or repaired post 1988, just after Texas PST rules went into effect. The duration of operations prior to tank removal or repair ranged from 2 to 52-yrs with an average of 17 years.
The fraction of soil organic carbon (foc) was reported at 61 sites and ranged between 0.001% and 13.2%, with a median value of 0.7%. Retardation coefficients (R) ranged from 1-7 for MTBE and 1 to 21 for benzene. The median hydraulic conductivity in the database was 2,625-ft/yr. Hydraulic gradients at 85% of the sites were less than or equal to 0.03 ft/ft and the median value for all sites was 0.01 ft/ft. Calculated seepage velocities ranged from less than 0.001-ft/yr to over 15,000-ft/yr. This range, while not typical for groundwater, is the result of very low hydraulic conductivities and steep gradients reported at several sites in the database. The median seepage velocity was 44-ft/yr. These hydrogeologic characteristics of the 127 sites point to the possible specificity of results from this study to the Gulf Coast region but also maybe due to the relatively small number of sites studied.
MTBE concentrations were significantly correlated to benzene and toluene, although the correlation was weaker than that between benzene and toluene. The stronger correlation between benzene and toluene likely reflects their comparable solubilities and other physical properties, as well as similar source terms. Maximum soil and groundwater concentrations varied greatly among the 127 sites. MTBE soil data were rarely found in site reports and a clear relationship between benzene soil and groundwater concentrations could not be found. The MTBE and benzene plumes at the majority of sites had traveled off-site and the off-site plumes were often not fully delineated. This is a key concern for assessing MTBE plume behavior since most existing monitoring networks do not capture the full extent of the plume. In fact, only 36 sites had extensive monitoring networks that allowed an adequate definition of their plumes. A comparison of average plume lengths for each constituent at the 36 sites is shown in Figure 3 (top). The benzene and MTBE plume lengths were comparable with average and median plume lengths of benzene actually outstretching those of MTBE by approximately 36-ft (11.0-m). The MTBE and benzene plumes ranged in length from 88- to 1096-ft and 78- to 1013-ft, respectively. In contrast, both benzene and MTBE significantly outstretched toluene, which at some sites had been reduced to below its MCL concentration in all wells. Based on the data in Figure 3, it was clear that the measured plume lengths reflect the order of associated MCL magnitude and is the probable cause for benzene plumes measuring longer than those for MTBE and the significantly smaller length of toluene plumes. In fact, when MTBE plumes and toluene plumes are contoured using the 5 ppb levels as in the case of benzene, MTBE plumes outstretch benzene and toluene by approximately 35% (Figure 3-bottom).
Figure 1. Histogram of Installation Dates for 127 sites in the Database
Figure 2. Histogram of Tank Removal Date for Sites in Database
Concentration trends were evaluated for 1,074 MTBE wells, 1,206 benzene wells, and 1,185 toluene wells. The majority of well concentrations (over 70%) were stable or declining over time for both MTBE and benzene. Results from the Mann Kendall and linear regression analyses indicated that MTBE and benzene stability were comparable in source and tail areas. The analysis of change in plume length over time, completed for the 36 sites with fully delineated MTBE and benzene plumes indicated that MTBE and benzene plume lengths were most often defined as stable or as having “no trend”. Toluene plumes, however, appeared to be more likely stable or decreasing and their concentration reduced to below the toluene MCL (1000-ppb) in all wells across several sites as mentioned previously.
Figure 3. Plume Lengths for MTBE, Benzene and Toluene (Top – using cleanup standards in defining plume, Bottom – using drinking water standards)
Plume lengths based on the average measurements over time were also evaluated for influences from source removal actions. The results showed that the median length of MTBE plumes was 65-ft longer at sites where source removal occurred after the first year plume data were contoured than those sampled after source removal.
The MTBE, benzene, and toluene well data yielded estimates of point and bulk attenuation rates. Median point attenuation rate constants (half-life) of –7.8E-04/d (2.45-yr) for MTBE and -7.5E-04/d (2.53-yr) for benzene were calculated. The median point attenuation rate constant calculated using 79% of all toluene wells was slightly higher at –8.6E-04/d (2.22-yr). Additionally, the median MTBE half-lives for decreasing source and tail wells were very comparable (2.55-yr versus 2.43-yr). It should be noted, however, that when only the 36 sites with fully delineated MTBE plumes were considered, a longer half-life was found for MTBE (4.4-yr) and benzene (4.3-yr). This supports the importance of adequate monitoring networks when analyzing plume behavior with time and assessing the viability of natural attenuation. Bulk attenuation rate constants for MTBE and benzene were also very comparable (3.33/yr and 2.7/yr, respectively).
Journal Articles:
No journal articles submitted with this report: View all 6 publications for this subprojectSupplemental Keywords:
